Note: Some computationally intensive examples below are shown with
eval=FALSEto keep CRAN build times short. For full rendered output, see the pkgdown site.
Latent Class Analysis (LCA)
LCA classifies examinees into unordered latent classes. Specify the dataset and the number of classes.
LCA(J15S500, ncls = 5)
#>
#> Item Reference Profile
#> IRP1 IRP2 IRP3 IRP4 IRP5
#> Item01 0.5185 0.6996 0.76358 0.856 0.860
#> Item02 0.5529 0.6276 0.81161 0.888 0.855
#> Item03 0.7959 0.3205 0.93735 0.706 0.849
#> Item04 0.5069 0.5814 0.86940 0.873 1.000
#> Item05 0.6154 0.7523 0.94673 0.789 0.886
#> Item06 0.6840 0.7501 0.94822 1.000 0.907
#> Item07 0.4832 0.4395 0.83377 0.874 0.900
#> Item08 0.3767 0.3982 0.62563 0.912 0.590
#> Item09 0.3107 0.3980 0.26616 0.165 0.673
#> Item10 0.5290 0.5341 0.76134 0.677 0.781
#> Item11 0.1007 0.0497 0.00132 0.621 0.623
#> Item12 0.0355 0.1673 0.15911 0.296 0.673
#> Item13 0.2048 0.5490 0.89445 0.672 0.784
#> Item14 0.3508 0.7384 0.77159 0.904 1.000
#> Item15 0.3883 0.6077 0.82517 0.838 0.823
#>
#> Test Profile
#> Class 1 Class 2 Class 3 Class 4 Class 5
#> Test Reference Profile 6.453 7.613 10.415 11.072 12.205
#> Latent Class Ditribution 87.000 97.000 125.000 91.000 100.000
#> Class Membership Distribution 90.372 97.105 105.238 102.800 104.484
#>
#> Item Fit Indices
#> model_log_like bench_log_like null_log_like model_Chi_sq null_Chi_sq
#> Item01 -264.179 -240.190 -283.343 47.978 86.307
#> Item02 -256.363 -235.436 -278.949 41.853 87.025
#> Item03 -237.888 -260.906 -293.598 -46.037 65.383
#> Item04 -208.536 -192.072 -265.962 32.928 147.780
#> Item05 -226.447 -206.537 -247.403 39.819 81.732
#> Item06 -164.762 -153.940 -198.817 21.644 89.755
#> Item07 -249.377 -228.379 -298.345 41.997 139.933
#> Item08 -295.967 -293.225 -338.789 5.483 91.127
#> Item09 -294.250 -300.492 -327.842 -12.484 54.700
#> Item10 -306.985 -288.198 -319.850 37.574 63.303
#> Item11 -187.202 -224.085 -299.265 -73.767 150.360
#> Item12 -232.307 -214.797 -293.598 35.020 157.603
#> Item13 -267.647 -262.031 -328.396 11.232 132.730
#> Item14 -203.468 -204.953 -273.212 -2.969 136.519
#> Item15 -268.616 -254.764 -302.847 27.705 96.166
#> model_df null_df NFI RFI IFI TLI CFI RMSEA AIC CAIC
#> Item01 9 13 0.444 0.197 0.496 0.232 0.468 0.093 29.978 -16.954
#> Item02 9 13 0.519 0.305 0.579 0.359 0.556 0.086 23.853 -23.079
#> Item03 9 13 1.000 1.000 1.000 1.000 1.000 0.000 -64.037 -110.969
#> Item04 9 13 0.777 0.678 0.828 0.744 0.822 0.073 14.928 -32.004
#> Item05 9 13 0.513 0.296 0.576 0.352 0.552 0.083 21.819 -25.112
#> Item06 9 13 0.759 0.652 0.843 0.762 0.835 0.053 3.644 -43.287
#> Item07 9 13 0.700 0.566 0.748 0.625 0.740 0.086 23.997 -22.934
#> Item08 9 13 0.940 0.913 1.000 1.000 1.000 0.000 -12.517 -59.448
#> Item09 9 13 1.000 1.000 1.000 1.000 1.000 0.000 -30.484 -77.415
#> Item10 9 13 0.406 0.143 0.474 0.179 0.432 0.080 19.574 -27.357
#> Item11 9 13 1.000 1.000 1.000 1.000 1.000 0.000 -91.767 -138.698
#> Item12 9 13 0.778 0.679 0.825 0.740 0.820 0.076 17.020 -29.912
#> Item13 9 13 0.915 0.878 0.982 0.973 0.981 0.022 -6.768 -53.699
#> Item14 9 13 1.000 1.000 1.000 1.000 1.000 0.000 -20.969 -67.901
#> Item15 9 13 0.712 0.584 0.785 0.675 0.775 0.065 9.705 -37.226
#> BIC
#> Item01 -7.954
#> Item02 -14.079
#> Item03 -101.969
#> Item04 -23.004
#> Item05 -16.112
#> Item06 -34.287
#> Item07 -13.934
#> Item08 -50.448
#> Item09 -68.415
#> Item10 -18.357
#> Item11 -129.698
#> Item12 -20.912
#> Item13 -44.699
#> Item14 -58.901
#> Item15 -28.226
#>
#> Model Fit Indices
#> Number of Latent class: 5
#> Number of EM cycle: 73
#> value
#> model_log_like -3663.994
#> bench_log_like -3560.005
#> null_log_like -4350.217
#> model_Chi_sq 207.977
#> null_Chi_sq 1580.424
#> model_df 135.000
#> null_df 195.000
#> NFI 0.868
#> RFI 0.810
#> IFI 0.950
#> TLI 0.924
#> CFI 0.947
#> RMSEA 0.033
#> AIC -62.023
#> CAIC -765.995
#> BIC -630.995The Class Membership Matrix indicates which latent class each examinee belongs to:
result.LCA <- LCA(J15S500, ncls = 5)
head(result.LCA$Students)
#> Membership 1 Membership 2 Membership 3 Membership 4 Membership 5
#> Student001 0.7839477684 0.171152798 0.004141844 4.075759e-02 3.744590e-12
#> Student002 0.0347378747 0.051502214 0.836022799 7.773694e-02 1.698776e-07
#> Student003 0.0146307878 0.105488644 0.801853496 3.343026e-02 4.459682e-02
#> Student004 0.0017251650 0.023436459 0.329648386 3.656488e-01 2.795412e-01
#> Student005 0.2133830569 0.784162066 0.001484616 2.492073e-08 9.702355e-04
#> Student006 0.0003846482 0.001141448 0.001288901 8.733869e-01 1.237981e-01
#> Estimate
#> Student001 1
#> Student002 3
#> Student003 3
#> Student004 4
#> Student005 2
#> Student006 4LCA Plot Types
- IRP: Item Reference Profile
- CMP: Class Membership Profile
- TRP: Test Reference Profile
- LCD: Latent Class Distribution
plot(result.LCA, type = "IRP", items = 1:6, nc = 2, nr = 3)
plot(result.LCA, type = "CMP", students = 1:9, nc = 3, nr = 3)
plot(result.LCA, type = "TRP")
plot(result.LCA, type = "LCD")
Latent Rank Analysis (LRA)
LRA is similar to LCA but assumes an ordering among the latent classes (ranks). Specify the dataset and the number of ranks.
LRA(J15S500, nrank = 6)
#> estimating method is GTM
#> Item Reference Profile
#> IRP1 IRP2 IRP3 IRP4 IRP5 IRP6
#> Item01 0.5851 0.6319 0.708 0.787 0.853 0.898
#> Item02 0.5247 0.6290 0.755 0.845 0.883 0.875
#> Item03 0.6134 0.6095 0.708 0.773 0.801 0.839
#> Item04 0.4406 0.6073 0.794 0.882 0.939 0.976
#> Item05 0.6465 0.7452 0.821 0.837 0.862 0.905
#> Item06 0.6471 0.7748 0.911 0.967 0.963 0.915
#> Item07 0.4090 0.5177 0.720 0.840 0.890 0.900
#> Item08 0.3375 0.4292 0.602 0.713 0.735 0.698
#> Item09 0.3523 0.3199 0.298 0.282 0.377 0.542
#> Item10 0.4996 0.5793 0.686 0.729 0.717 0.753
#> Item11 0.0958 0.0793 0.136 0.286 0.472 0.617
#> Item12 0.0648 0.0982 0.156 0.239 0.421 0.636
#> Item13 0.2908 0.4842 0.715 0.773 0.750 0.778
#> Item14 0.4835 0.5949 0.729 0.849 0.933 0.977
#> Item15 0.3981 0.5745 0.756 0.827 0.835 0.834
#>
#> Item Reference Profile Indices
#> Alpha A Beta B Gamma C
#> Item01 3 0.0786 1 0.585 0.0 0.00000
#> Item02 2 0.1264 1 0.525 0.2 -0.00787
#> Item03 2 0.0987 2 0.610 0.2 -0.00391
#> Item04 2 0.1864 1 0.441 0.0 0.00000
#> Item05 1 0.0987 1 0.647 0.0 0.00000
#> Item06 2 0.1362 1 0.647 0.4 -0.05198
#> Item07 2 0.2028 2 0.518 0.0 0.00000
#> Item08 2 0.1731 2 0.429 0.2 -0.03676
#> Item09 5 0.1646 6 0.542 0.6 -0.07002
#> Item10 2 0.1069 1 0.500 0.2 -0.01244
#> Item11 4 0.1867 5 0.472 0.2 -0.01650
#> Item12 5 0.2146 5 0.421 0.0 0.00000
#> Item13 2 0.2310 2 0.484 0.2 -0.02341
#> Item14 2 0.1336 1 0.484 0.0 0.00000
#> Item15 2 0.1817 2 0.574 0.2 -0.00123
#>
#> Test Profile
#> Rank 1 Rank 2 Rank 3 Rank 4 Rank 5 Rank 6
#> Test Reference Profile 6.389 7.675 9.496 10.631 11.432 12.144
#> Latent Rank Ditribution 96.000 60.000 91.000 77.000 73.000 103.000
#> Rank Membership Distribution 83.755 78.691 81.853 84.918 84.238 86.545
#>
#> Item Fit Indices
#> model_log_like bench_log_like null_log_like model_Chi_sq null_Chi_sq
#> Item01 -264.495 -240.190 -283.343 48.611 86.307
#> Item02 -253.141 -235.436 -278.949 35.409 87.025
#> Item03 -282.785 -260.906 -293.598 43.758 65.383
#> Item04 -207.082 -192.072 -265.962 30.021 147.780
#> Item05 -234.902 -206.537 -247.403 56.730 81.732
#> Item06 -168.218 -153.940 -198.817 28.556 89.755
#> Item07 -250.864 -228.379 -298.345 44.970 139.933
#> Item08 -312.621 -293.225 -338.789 38.791 91.127
#> Item09 -317.600 -300.492 -327.842 34.216 54.700
#> Item10 -309.654 -288.198 -319.850 42.910 63.303
#> Item11 -242.821 -224.085 -299.265 37.472 150.360
#> Item12 -236.522 -214.797 -293.598 43.451 157.603
#> Item13 -287.782 -262.031 -328.396 51.502 132.730
#> Item14 -221.702 -204.953 -273.212 33.499 136.519
#> Item15 -267.793 -254.764 -302.847 26.059 96.166
#> model_df null_df NFI RFI IFI TLI CFI RMSEA AIC CAIC
#> Item01 9.233 13 0.437 0.207 0.489 0.244 0.463 0.092 30.146 -17.999
#> Item02 9.233 13 0.593 0.427 0.664 0.502 0.646 0.075 16.944 -31.201
#> Item03 9.233 13 0.331 0.058 0.385 0.072 0.341 0.087 25.293 -22.852
#> Item04 9.233 13 0.797 0.714 0.850 0.783 0.846 0.067 11.555 -36.590
#> Item05 9.233 13 0.306 0.023 0.345 0.027 0.309 0.102 38.264 -9.881
#> Item06 9.233 13 0.682 0.552 0.760 0.646 0.748 0.065 10.091 -38.054
#> Item07 9.233 13 0.679 0.548 0.727 0.604 0.718 0.088 26.504 -21.641
#> Item08 9.233 13 0.574 0.401 0.639 0.467 0.622 0.080 20.326 -27.820
#> Item09 9.233 13 0.374 0.119 0.451 0.156 0.401 0.074 15.751 -32.394
#> Item10 9.233 13 0.322 0.046 0.377 0.057 0.330 0.085 24.445 -23.700
#> Item11 9.233 13 0.751 0.649 0.800 0.711 0.794 0.078 19.006 -29.139
#> Item12 9.233 13 0.724 0.612 0.769 0.667 0.763 0.086 24.985 -23.160
#> Item13 9.233 13 0.612 0.454 0.658 0.503 0.647 0.096 33.037 -15.108
#> Item14 9.233 13 0.755 0.654 0.809 0.723 0.804 0.073 15.034 -33.111
#> Item15 9.233 13 0.729 0.618 0.806 0.715 0.798 0.060 7.593 -40.552
#> BIC
#> Item01 -8.767
#> Item02 -21.969
#> Item03 -13.620
#> Item04 -27.357
#> Item05 -0.648
#> Item06 -28.822
#> Item07 -12.408
#> Item08 -18.587
#> Item09 -23.162
#> Item10 -14.467
#> Item11 -19.906
#> Item12 -13.927
#> Item13 -5.875
#> Item14 -23.879
#> Item15 -31.319
#>
#> Model Fit Indices
#> Number of Latent rank: 6
#> Number of EM cycle: 17
#> value
#> model_log_like -3857.982
#> bench_log_like -3560.005
#> null_log_like -4350.217
#> model_Chi_sq 595.954
#> null_Chi_sq 1580.424
#> model_df 138.491
#> null_df 195.000
#> NFI 0.623
#> RFI 0.469
#> IFI 0.683
#> TLI 0.535
#> CFI 0.670
#> RMSEA 0.081
#> AIC 318.973
#> CAIC -403.203
#> BIC -264.712Rank membership probabilities and rank-up/rank-down odds are calculated:
result.LRA <- LRA(J15S500, nrank = 6)
head(result.LRA$Students)
#> Membership 1 Membership 2 Membership 3 Membership 4 Membership 5
#> Student001 0.2704649921 0.357479353 0.27632327 0.084988078 0.010069050
#> Student002 0.0276546965 0.157616072 0.47438958 0.279914853 0.053715813
#> Student003 0.0228189795 0.138860955 0.37884545 0.284817610 0.120794858
#> Student004 0.0020140858 0.015608542 0.09629429 0.216973334 0.362406292
#> Student005 0.5582996437 0.397431414 0.03841668 0.003365601 0.001443909
#> Student006 0.0003866603 0.003168853 0.04801344 0.248329964 0.428747502
#> Membership 6 Estimate Rank-Up Odds Rank-Down Odds
#> Student001 0.0006752546 2 0.7729769 0.7565891
#> Student002 0.0067089816 3 0.5900527 0.3322503
#> Student003 0.0538621490 3 0.7518042 0.3665372
#> Student004 0.3067034562 5 0.8462973 0.5987019
#> Student005 0.0010427491 1 0.7118604 NA
#> Student006 0.2713535842 5 0.6328983 0.5791986
plot(result.LRA, type = "IRP", items = 1:6, nc = 2, nr = 3)
plot(result.LRA, type = "RMP", students = 1:9, nc = 3, nr = 3)
plot(result.LRA, type = "TRP")
plot(result.LRA, type = "LRD")
LRA for Ordinal Data
LRA can also handle ordinal scale data. The mic option
enforces monotonic increasing constraints.
result.LRAord <- LRA(J15S3810, nrank = 3, mic = TRUE)Score-rank relationship visualizations:
Item-rank relationship plots:
- ICBR: Item Category Boundary Reference – cumulative probability curves for each category threshold
- ICRP: Item Category Response Profile – probability of each response category across ranks
plot(result.LRAord, type = "ICBR", items = 1:4, nc = 2, nr = 2)
plot(result.LRAord, type = "ICRP", items = 1:4, nc = 2, nr = 2)Rank membership profiles for individual examinees:
plot(result.LRAord, type = "RMP", students = 1:9, nc = 3, nr = 3)
